Transcell Technology TI-1680 Manual

36
ERROR MESSAGES
The weighing capacity of the scale has been ex-
ceeded. (Gross overload)
The weight on the scale is below Gross zero. Press
the ZERO key.
Err 3
Non-volatile memory read error.
Err 4
Non-volatile memory write error.
Err 6
Keyboard tare value exceeds scales capacity.
Err 9
Span calibration values have been lost.
Err 10
Not in Gross mode.
(Weigh-in/weigh-out application)
Err 11
Scale is displaying a negative weight value.
(Weigh-in/weigh-out application)
SPECIFICATIONS
Enclosure: Stainless Steel (IP67)
Display: 1" (25 mm) 7-segment, LED, 6 Digit
A-to-D converter: AD-01
Resolution: Approximately 400,000 counts at 3mV/V input
Sampling Rate: 10 Hz or 80 Hz, selectable
Excitation Voltage: +5 VDC, 12 x 350Ω load cells
Input Signal Range: ±3.125 mV/V
Serial Ports: Two (2) Full Duplex RS-232C
Operating Temperature: 14°F to 104°F (-10°C to 40°C)
Power: 100-240 VAC, 50-60 Hz, 0.8A
