RS-232 Connections (COM1)
Connect your RS-232 serial cable to the COM1 / RS-232 terminal block using the table below.
COM1 / RS-232 Terminal Block (J10)
Markings
Function
GND
Signal Ground
RTS
Request to Send
CTS
Clear to Send
TxD1
Transmit Data
RxD1
Receive Data
COM1 / RS-232 Terminal Block
RS-232 Connections (COM2)
Connect your RS-232 serial cable to the COM2 / RS-232 terminal block using the table below.
COM1 / RS-232 Terminal Block (J9)
Markings
Function
GND
Signal Ground
RTS
Request to Send
CTS
Clear to Send
TxD2
Transmit Data
RxD2
Receive Data
COM2 / RS-232 Terminal Block
