5
The keypad comprises a total of twenty-four (24) keys: twelve (12) function keys and twelve (12)
numeric keypad keys.
“Function Keys”
Cycles the displayed weight indication among pounds (lb), kilograms (kg), and a selectable
third unit. This key can be disabled.
Zeroes the weight display reading, provided certain conditions are met.
Cycles the displayed weight indication among Gross weight, Net Weight, and Tare Weight.
Establishes a system Tare, provided certain conditions are met.
Sends the displayed weight reading to the serial communication port, provided certain con-
ditions are met.
Exits current function. Can also be used as a backspace key during numeric entry.
Main function key for a specification application, e.g., piece counting or peak hold
Used to enter the set points (target weights) into the system.
Used to enter the minimum target weight for Checkweigher mode.
Used to enter the maximum target weight for Checkweigher mode.
Used to enter an ID number into the system.
Used to enter numeric data into the system.
Certain keys may be password protected. See Advanced Operation section for more details.
