#8151 Set Check Tag Address to 1 on Check Tag pin 0.
Reader response: #Done
#8152 Set Check Tag Address to 0 on Check Tag pin 1.
Reader response: #Done
#8153 Set Check Tag Address to 1 on Check Tag pin 1.
Reader response: #Done
Note: The MPRX transmits ID codes to the host device when the MPRX is in data mode.
01 Switch to Command Mode
#01 switches the reader to command mode, which allows the reader to accept commands
from a host or terminal. While in command mode, the reader turns RF o and does not
acquire tags.
Reader response: #Done
Communications port Control — Command Group 1
Group 1 commands configure the parameters used by the MPRX to communicate with a host device or
terminal. These commands set baud rate, stop bits, parity, and end-of- line delay.
100N Select Baud Rate
#100N selects the reader baud rate. The factory-default setting is 9600 baud. The N variable
specifies the baud rate shown in Table 12.
Table 12 Select Baud Rate Commands
Command Baud Rate Selected
1002
1200
1003
2400
1004
4800
1005
9600 (factory default)
1006
19.2 K
1007
38.4 K
Reader response: #Done
Caution
If ECP is enabled, ensure that the ECP timeout is sucient for the new baud rate. .
101N Select Stop Bits
#101N selects the number of stop bits for reader character transmission. The factory default
setting is 1 stop bit. The N variable specifies the number of stop bits as indicated in
Table 13.
