Environmental Parameters
Operating Temperature -40°F to +158°F (-40°C to +70°C)
Humidity 99% condensing
Ingress Protection IP65/IP67 Rated, with appropriate connectors.
Vibration Tolerance
The MPRX complies with vibration tolerance limits
specified in AREMA C&S Manual, Part 11.5.1, Class C
Operation Shock
Tolerance
The MPRX complies with shock tolerance limits
specified in AREMA C&S Manual, Part 11.5.1, Class C
Reader Dimensions
Figure 25 illustrates the exterior dimensions of the MPRX case.
Figure 25 MPRX Exterior Case Dimensions
MPRX User Guide
TransCore Proprietary
B–112
