Table 24 Timeout Period Values
Command Timeout (ms)
6938
60
6939
92
693A
152
693B
300
693C
452
693D
600
693E
752
693F
Infinite (never expires,
factory default)
Reader response: #Done or #Error.
The reader returns an Error message if a valid hexadecimal digit is not substituted for N in Command
#693N.
Note: This command only has an eect when the reader is not in MPRX mode.
694N Select Input Inversion Option
#694N enables or disables input inversion. When inversion is enabled, an open circuit input
is interpreted as a closed circuit, and a closed circuit input is interpreted as an open
circuit. This feature allows greater flexibility in the attachment of external equipment to
the reader inputs. For example, some proximity sensors indicate presence with an open
circuit. In this instance, Command #6941 can enable input inversion so that an open
circuit input indicates a presence. The values for N represent the two inversion options
as shown in Table 25.
Reader response: #Done
Table 25 Input Inversion Options
Command Option
6940
Disable input inversion (factory default)
6941
Enable input inversion
695S...S Set Serial Number (Factory Default)
#695 assigns the reader serial number according to the format:
695SSSSSS
where
SSSSSS is the serial number.
MPRX User Guide
TransCore Proprietary
5–80
