TransCore MPRX Series - Table 34 MPRX SENSE Communications Cable Pin Designations; Table 35 Ethernet Pin Designations

Table 34 lists the MPRX Sense Communications Cable Pin Designations. For TransCore part numbers,
refer to “Pretest Accessory Options Available From TransCore” on page 2–26.
Table 34 MPRX SENSE Communications Cable Pin Designations
SENSE CABLE
PAIR COLOR PIN NUMBER NAME
1
black or gray 3 I/O GND
red 1 12VDC OUT (CTG)
2
black or gray 6 OUT 0
white 2 OUT 1
3
black or gray 7 CTAG 0
green 8 CTAG 1
4
black or gray 4 I/O GND
blue 5 PULSE OUT
5
black or gray 10 I/O GND
brown 12 SENSE 0
6
black or gray 9 I/O GND
yellow 11 SENSE 1
Table 35 lists the MPRX Ethernet wiring pin designations.
Table 35 Ethernet Pin Designations
Pin Number Operation
1 Receive +
2 Transmit +
3 Receive -
4 Transmit -
