Description
Technical data
30
Operating instructions: Indexing conveyor/short track conveyor TS 1300
Version 3.6ENG, 28.02.2019
Motor brake voltage Standard: 230 V AC/400 V AC, please refer to
motor type identification plate for optional devia-
tions
Protection class Standard: IP55, not explosion-protected
Installation location requirements
Name Data
Ambient temperature +5 °C to +40 °C, up to +50 °C temporarily (max. 1
h)
Relative air humidity Max. 80 %
Surrounding atmosphere Normal atmosphere, no explosive atmospheres,
does not contain oil or gas, no corrosive compo-
nents
Installation Internally: Well protected from rain; only securely
bolted to solid base
Other data
Name Data
Year of construction Please refer to type identification plate
Noise emission Sound pressure level measured in accordance with
DIN EN 13023:2003-03 below 77 dB(A).
Electrical data (contd.)
Name Data
