transnorm TS 1300 - Auxiliary Equipment

Transportation and installation
Internal transportation
38
Operating instructions: Indexing conveyor/short track conveyor TS 1300
Version 3.6ENG, 28.02.2019
Auxiliary equipment
Required auxiliary equipment
Overhead crane, gantry crane Safe working load 2000 kg
Industrial truck Safe working load 2000 kg
Min. lifting height 4000 mm
Lift truck cross beam,
safe working load 2000 kg
Lift truck hook,
safe working load 2000 kg
Adjustable cross beam,
safe working load 2000 kg
L max. = 4000 mm
L min. = 2000 mm
Adjustable cross beam, double
safe working load 2000 kg
La max. = 4000 mm
La min. = 2000 mm
Lb max. = 2000 mm
Lb min. = 1000 mm
Round slings,
safe working load 1000 kg
U min = 3 m
