transnorm TS 1300 - Areas of the Machine

Description
Areas of the machine
32
Operating instructions: Indexing conveyor/short track conveyor TS 1300
Version 3.6ENG, 28.02.2019
Areas of the machine
The machine consists of the following areas:
TS 1300 assemblies
Key to illustration
No. Name
1 Side guide
2 Supports
3 Conveyor track
4 Drive assembly
5 Tail pulley assembly
5
3
1
2
4
