transnorm TS 1300 - Disassembling;Assembling the Bottom Cover

Maintenance and repair
Disassembling/assembling the bottom cover
60
Operating instructions: Indexing conveyor/short track conveyor TS 1300
Version 3.6ENG, 28.02.2019
Disassembling/assembling the bottom cover
Requirements:
 Machine has been taken out of operation.
 Machine has been secured to prevent it from being switched on inadvert-
ently.
 Disassemble the
bottom cover
WARNING
Increased risk of accident!
The bottom cover may tilt and crush parts of the body.
 Secure the bottom cover to prevent it from falling.
Complete the following steps:
1. Release the joining elements (1).
2. Remove the cover (2).
 The bottom cover has been removed.
 Assemble the
bottom cover
Complete the following steps:
 Assembly must be carried out in the reverse order.
 The bottom cover has been assembled.

The bottom cover has been removed/fitted.
1
2
