Transportation and installation
Final installation on-site
43
Align and anchor the
machine, all types
Risk of fatal injury from crushing to parts of the body!
If supports are not anchored, the machine can topple and fall over when
moved to position it.
Before aligning it, lift the machine with suitable hoists. Please refer to the
information in the section "Internal transportation".
Risk of fatal injury from crushing to parts of the body!
The machine may slip when you loosen the fixing screws for adjusting the
height.
When adjusting supports or suspensions, ensure that the conveyor is
additionally supported.
Use retaining bolts to create a form-fitting connection for suspensions.
Complete the following steps:
1. Align the machine horizontally and free of torsion in accordance with the
required infeed and outfeed height. To do this, loosen the fixing screws
for support height adjustment.
2. Check the levelling. Observe the correct heights for infeed and outfeed.
Depending on the system design, different heights may be recom-
mended. The system design engineer will advise on this.
3. Only in the case of floor anchorage: Anchor the supports so they can no
longer change position. The foot plates of the supports are equipped with
corresponding bore holes.
4. Only in the case of ceiling suspension: Anchor the suspensions so that
they can no longer change position. The plates of the suspensions have
corresponding bore holes.
5. Use retaining bolts to secure all joints creating a form-fitting connection.
6. Manually check the transfer accuracy at the front and back of the
machine. Use loads according to specifications to carry out this check.
The machine has been aligned.
The machine has been installed and aligned.
