TRENDnet TEW-718BRM User Manual

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-718BRM
14
Selecting WEP:
If selecting WEP (Wired Equivalent Privacy), please review the WEP settings to configure
and click Apply to save the changes.
• Encryption – Choose Open, Shared, or Auto.
Note: It is recommended to use Open System because it is known to be more secure
than Shared Key.
• WEP Key 1-4
o Choose HEX or ASCII.
Note: It is recommended to use ASCII because of the much larger
character set that can be used to create the key.
o This is where you enter the password or key needed for a computer to
connect to the router wirelessly
o You can define up to 4 passwords or 4 keys. Only one key can be active
at a given time. Most users simply define one key.
o Choose a key index 1, 2, 3, or 4 and enter the key.
o When connecting to the router, the client must match both the
password and the Key number. (e.g. if you have activated Key 2 with a
password of 12345, then the client must select: Key 2 (entering Key 1,
3, or 4 will block the ability to connect) and enter password 12345)
Selecting WPA-PSK, WPA-PSK / WPA2-PSK, or WPA2-PSK (WPA2-PSK recommended):
If selecting WPA-PSK, WPA-PSK / WPA2-PSK, or WPA2-PSK, (Wi-Fi Protected Access
Preshared Key) please review the settings to configure and click Apply to save the
changes.
First, from the Security Mode drop-down list, select WPA-PSK, WPA-PSK / WPA2-PSK,
or WPA2-PSK.
o Select the Encryption type. When selecting WPA-PSK security, it is
recommended to use TKIP.
o When selecting WPA-PSK / WPA2-PSK security, it is recommended to
use AES.
o When selecting WPA2-PSK security, it is recommended to use AES.
Create your Wireless security preshared key (password or key):
• Preshare Key – Enter the preshared key.
o This is the password or key that is used to connect your computer to
this router wirelessly
Note: 8-63 alphanumeric characters (a,b,C,?,*, /,1,2, etc.)
Then from the PSK/EAP row, select either PSK or EAP
• PSK stands for Preshared Key
• EAP stands for Extensive Authentication Protocol, also called Remote
Authentication Dial-In User Service or RADIUS).
Note: EAP requires an external RADIUS server, PSK only requires you to create a
passphrase.
WEP Key Format
HEX ASCII
Character set 0-9 & A-F, a-f only Alphanumeric (a,b,C,?,*, /,1,2, etc.)
64-bit key length 10 characters 5 characters
128-bit key length 26 characters 13 characters

TRENDnet TEW-718BRM Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Rack mounting	No
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DSL specification	G.992.1, G.992.2, G.992.3, G.992.5
DHCP client	-
Routing protocols	IGRP, IP, RIP-1, RIP-2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2-PSK
Antennas quantity	1
Certification	CE, FCC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	5 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Product color	Black
LED indicators	DSL, LAN, WLAN

Weight and Dimensions

Depth	189 mm
Width	118 mm
Height	33 mm
Weight	221 g
