TRENDnet TEW-718BRM User Manual

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-718BRM
6
Router Installation
Before you Install
Many Internet Service Providers (ISPs) allow your router to connect to the Internet
without verifying the information fields listed below. Skip this section for now and if
your router cannot connect to the Internet using the standard installation process, come
back to this page and contact your ISP to verify required ISP specification fields listed
below.
General ADSL Parameters
VCI: ____
VPI: ____
MTU: ________
Data Encapsulation (LLC/VCMux) : _________
Schedule Type (UBR/CBR/VBR/GFR): _______
VLAN Tag (If required by your ISP): _________
ADSL Connection Types:
1. Ethernet over ATM (RFC 1483 Bridged) with NAT
• 1a. Obtain IP Address Automatically (Dynamic IP Address)
Host Name (Optional) ______________________
ISP registered Mac Address or Clone MAC address (Optional)___:___:___:___:___:___
• 1b. Fixed IP address (Static IP Address)
WAN IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
WAN Subnet Mask: _____. _____._____._____
WAN Gateway IP Address: _____. _____._____._____
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
2. IP over ATM (RFC 1483 Routed)
• 2a. Obtain IP Address Automatically (Dynamic IP Address)
Host Name (Optional) ______________________
ISP registered Mac Address or Clone MAC address (Optional)___:___:___:___:___:___
• 2b . Fixed IP address (Static IP Address)
WAN IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
WAN Subnet Mask: _____. _____._____._____
WAN Gateway IP Address: _____. _____._____._____
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
3. PPP over ATM (PPPoE)
• 3a. PPPoE to obtain IP automatically
Account/User Name: _________
Password: ________________
• 3b. PPPoE with a fixed IP address
User Name: _________
Password: ________________
Verify Password: ________________
IP Address: ____. _____._____._____ (e.g. 215.24.24.129)
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____
4. PPP over Ethernet (PPPoA)
• 4a. PPPoA to obtain IP automatically
Account/User Name: _________
Password: ________________
• 4b. PPPoA with a fixed IP address
User Name: _________
Password: ________________
Verify Password: ________________
IP Address: ____. _____._____._____ (e.g. 215.24.24.129)
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Server Address: _____. _____._____._____

TRENDnet TEW-718BRM Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Modulation	16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Rack mounting	No
Frequency band	2.4 GHz
Frequency range	2.4 - 2.4835 GHz
WLAN data transfer rates supported	11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports	4
DSL specification	G.992.1, G.992.2, G.992.3, G.992.5
DHCP client	-
Routing protocols	IGRP, IP, RIP-1, RIP-2
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2-PSK
Antennas quantity	1
Certification	CE, FCC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	5 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Product color	Black
LED indicators	DSL, LAN, WLAN

Weight and Dimensions

Depth	189 mm
Width	118 mm
Height	33 mm
Weight	221 g
