Quick Guide
Before turning on the power
Initial auto installation
WhentheReceiverispoweredonforthersttime,theFirst Time Installation screen appears.
Follow the on-screen instructions to search for all available channels.
Conrm the following before turning on the power
• Istheantennacableconnected?
• Isthereceiverpluggedintoamainssocket?
• IstheHDMI™cableconnectedbetweenthereceiverandyourTV?
1 Ensure the antenna cable is connected before switching on.
2 Press the key on the Receiver or Remote Control.
• The First Time Installation screen is displayed.
3 Highlight Start Search, and press OK to start the channel search.
• The Receiver will search for, sort and store all receivable channels.
NOTE
• After the First Time Installation has been completed,
the default PIN is automatically set to ‘0000’.
To change the PIN setting, refer to Page 23.
1 Connect the antenna (IEC 169-2) coaxial plug to RF IN.
Use CAI Benchmarked 75 ohm coaxial cable such as Triax TX100
2 Connect the HDMI™ cable
3 Plug in the receiver and switch socket on
1
2
3
