Accessories, Loading and Passengers
115
Loading Distribution
The maximum payload which may be carried on the motorcycle in all storage locations is given
below; noting that the maximum vehicle loading weight of 526 lbs (239 kg) must not be
exceeded.
This maximum loading weight is made up from the combined weight of the rider, passenger,
any accessories fitted and the load carried.
Storage location Maximum payload
Pannier 22 lbs (10 kg) (in each pannier)
Top box (if equipped) 22 lbs (10 kg)
Luggage rack and seat (if no top box fitted) up to 22 lbs (10 kg) total
Cockpit stowage box 3.3 lbs (1.5 kg)
Under-seat stowage box (with and without
audio fitted)
1.1lbs (0.5 kg) (with audio)
3.8 lbs 1.7 kg (without audio)
Triumph accessory D-lock (if equipped) 5.6 lbs (2.7 kg)
