36
General Information
If the coolant temperature becomes too high
the display will show eight bars and will start
to flash. The high coolant temperature light in
the tachometer will also be illuminated and
COOLANT TEMP HIGH will be visible in the
lower message screen.
1. High coolant temperature warning
light
2. Instrument message
Fuel Gauge
1. Fuel gauge
The fuel gauge indicates the amount of fuel
in the tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel.
When the fuel tank is full all 8 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
When 1.9 US gallons (4.5 liters) of fuel
remain the low fuel warning light will
illuminate (see page 26), a few seconds later
the display screen will switch to 'Range'
display (see page 42). This indicates there are
approximately 1.9 US gallons (4.5 liters) of
fuel remaining in the tank and you should
refuel at the earliest opportunity.
After refuelling, the fuel gauge and range to
empty information will be updated only while
riding the motorcycle. Depending on the
riding style, updating could take up to
five minutes.
