54
General Information
System Display
1. T P M S s y m b o l
2. Tire pressure display
The tire pressure display can be accessed
through Trip 1 or Trip 2 (see page 41 ).
When the tire pressure monitoring system
has been selected, — — PSI or BAR
(information on how to set the desired display
units can found on page 49) will be visible,
for each tire, in the display screen until the
motorcycle is travelling at a speed greater
than 12 mph (20 km/h) and the tire pressure
signal is received.
Sensor Batteries
When the battery voltage in a pressure
sensor is low, TPMS - BATTERY LOW
FRONT/REAR TIRE will be displayed for
eight seconds. If the batteries are completely
flat, only dashes will be visible in the display
screen, the red TPMS warning light will be
on and the TPMS symbol will flash
continuously. Contact your authorized
Triumph dealer to have the sensor replaced
and the new serial number recorded in the
spaces provided on page 53.
1. Tire pressure warning light
2. Instrument message
TPMS Symbol
With the ignition switch turned to the ON
position, if the TPMS symbol flashes for
10 seconds and then remains on there is a
fault with the TPMS system. The message
CHECK MANUAL - TPMS SYSTEM FAULT -
SENSOR SIGNAL will be displayed for
eight seconds in the lower message area.
Contact your authorized Triumph dealer to
have the fault rectified.
