83
General Information
Electrical Accessory Sockets
Up to four electrical accessory sockets are
provided on the motorcycle, as described
below:
• All models have a socket fitted to the left
hand side of the engine, below the
rider’s seat, and a socket fitted in the
stowage box.
1. Engine mounted socket
2. Stowage box socket
• Trophy SE models have a pillion socket
fitted on the left hand side of the
motorcycle, below the luggage rack. This
socket is available as an accessory kit for
Trophy models from your authorized
Triu mph deal er.
• Models fitted with a Triumph top box
have a socket located inside the top box.
1. Pillion socket
2. Top box socket
chto
2
1
