79
General Information
Operation:
Both of the switches are connected into the
ignition circuit, and will only heat when the
engine is running.
The system is designed to offer two heat
levels, hot or warm.
For maximum benefit in cold conditions,
position the switch to the hot position initially
and then to the warm position when the seats
have warmed up.
The status of the heated seats is displayed in
the multi-function display screen (see
page 37).
Triumph Accessory D-lock
Storage
Space is provided under the rear seat to store
a Triumph accessory D-lock (available from
your Triumph dealer).
Secure the lock as follows:
Remove the rear seat (see page 76).
Release the straps and remove the tool kit.
Position the U-section of the lock to the rear
fender tray support features, ensuring the
open end faces towards the rear of the
motorcycle.
Position the lock body into the rear fender
tray as shown below.
1. Lock U-section
2. Lock body
3. Tool kit
4. Straps
Fit the tool kit above the D-lock and secure
using the rear strap.
Secure the lock body with the front strap,
ensuring it passes under the U-section of the
lock as shown.
Re-install the rear seat (see page 76).
