Parts Identification
PARTS IDENTIFICATION
1. Headlight
2. Front turn signal
3. Accessory socket
4. Front heated seat switch (if
equipped)
5. Fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. Accessory socket (if equipped)
8. Accessory socket (if top box
equipped)
9. Seat lock
10. Rear brake caliper
11. C e n t e r s t a n d
12. Rear suspension spring rebound
damping adjuster (models without
Triumph Electronic Suspension (TES))
13. Gear-change pedal
14 . S i d e s t a n d
15. Coolant expansion tank
16. Front brake caliper
17. Front brake disc
chqw
12468
111213151617
14 910
3
7
5
