35
General Information
Gear Position Display
1. Gear position display (neutral
position shown)
2. Neutral light
The gear position display indicates which
gear (1 to 6) has been engaged. When the
transmission is in neutral (no gear selected),
the display will show N and the neutral light
will illuminate.
1. Gear position display (first gear
shown)
Coolant Temperature Gauge
1. Coolant temperature gauge
The coolant temperature gauge indicates the
temperature of the engine coolant.
When the ignition is switched on, all eight
bars of the display will be shown. When the
engine is started from cold the display will
show no bars. As the temperature increases
more bars in the display will be shown. When
the engine is started from hot the display will
show the relevant number of bars,
dependant on engine temperature.
The normal temperature range is between
four and five bars.
