16
Parts Identification
Parts Identification (continued)
1. C l u t c h l e v e r
2. Passing button
3. Headlight dimmer switch
4. Instrument's scroll button
5. Clutch fluid reservoir
6. Speedometer
7. H az a rd w a rn i n g light button
8. Multi-function display screen
9. Tachometer
10. Front brake fluid reservoir
11. R e a r v i e w m i r r o r
12. Front brake lever
13. Engine stop switch
14. Starter button
15. Cruise control adjust button
16. Cruise control ON/OFF button
17. Ignition switch
18. Fuel filler cap
19. Audio controls (models fitted with
audio system)
20. Windshield adjustment switch
21. Heated grip switch
22. Instrument's select button
23. Direction turn signal switch
24. Horn button
