Trocen AWC78 Series User Manual

AWC7813 motion controller user manual
WWW.SZTROCEN.COM
5
Wiring board (base
plate)
The wiring board is a control board that controlling
integrated signal input and output and connecting motor
driver.
System hardware
The physical objects visible to the system, including: panel,
wiring board, wires, etc.
1.4 AWC7813 accessories composition
After receiving the product, please confirm whether the product and
accessories are complete. If there is any missing, please contact Shenzhen Trocen
Automation Technology Co. Ltd. after-sales customer service.
1.4.1 AWC7813 all accessories and connection diagram

Trocen AWC78 Series Specifications

General

Brand	Trocen
Model	AWC78 Series
Category	Security Sensors
Language	English
