AWC7813 motion controller user manual
WWW.SZTROCEN.COM
8
1.5 Appearance and size of panel
Figure1-5-1 Panel appearance display
Figure1-5-2 Panel size diagram
142mm
30mm
3mm
154mm
113mm
113mm
C
93mm
142mm
CN1
154mm
5-inch touch screen
U Disk Jack
154mm
