Trocen AWC78 Series User Manual

AWC7813 motion controller user manual
WWW.SZTROCEN.COM
16
double-driver control function is effective. Please refer to Y&Z double-driver control
related content 3.16.6.2 Y＆Z Double-Driver Control.
2.2.6 Limit signal input port
The wiring board can provide the limit signal access of 3 limit sensors.
Each axis can provide two limit signal input of maximum coordinate and
minimum coordinate.
1) X/Y limit signal input
Terminal group
Silk screen
Description
6P terminals
GND
Power ground-output signal
X-
X-axis origin limit-the input signal of the
limit sensor at the minimum coordinate
Y-
Y-axis origin limit-the input signal of the
limit sensor at the minimum coordinate
X+
X-axis hard limit-the input signal of the
limit sensor at the maximum coordinate.
X+ limit port generally does not need
wiring, just setting the format. For related
content, see 3.16.1.6 Range(mm).
Y+
Y-axis hard limit-the input signal of the
limit sensor at the maximum coordinate.
Y+ limit port generally does not need
wiring, just setting the format. For related
content, see 3.16.1.6 Range(mm).
24V
24V power supply positive output
