AWC7813 motion controller user manual
during idling, but not during processing.
When the laser head always emits light during idling, but does not emit light
during cutting, it can be inferred that the setting of 【TTL Valid level】 is wrong, and
then select the opposite effective level.
3.16.2.3 PWM Frequency(hz)
【PWM frequency】 refers to the pulse frequency used to set the control signal
used by the laser (refer to the laser tube manual), the higher the frequency, the
faster the work. Generally, the laser frequency of CO2 glass tube is 20000, and the
laser frequency of RF tube is 5000.
3.16.2.4 Max Power(%)
【Max power】 refers to the limit power of the laser tube. The laser power and
the power of the processing file cannot be higher than the maximum power. The
laser power is displayed as a percentage, generally set to 98% to prevent damage to
the machine due to excessive power. For the laser power and processing file power,
please refer to 3.10.1 Modify Laser power、Table3-7-2 description of layer parameters.
3.16.2.5 RF Min Power(%)
In order to prevent the radio frequency tube from leaking light in the standby
state, the minimum power of the radio frequency tube needs to be set. The
minimum power of the laser tube (refer to the laser tube manual) is generally set
between 6%-10%.
3.16.2.6 Laser 1 Water Protect
【Laser 1 Water Protect】 refers to the switch of laser 1 water protection, if you
To Next Page
