Trotec SP3000 Operation Manual

SP3000
Technical Data
32 / 87 BA 8034_2.4_EN (12/2016)
www.troteclaser.com
Laser
Laser system
Sealed-off CO
2
laser
Laser power
60, 100, 200 and 400 watts
Cooling
Water cooled
Wavelength
10,6 µm
Options
JobControl
®
Vision
Camera compensation system for print & cut applications
Travelling exhaust
Exhaust mounted to working head
Digital table exhaust
Digitally controlled sectioning of table exhaust; 4 exhaust sections
Chiller
For all power levels
Sonar Technology
TM
Ultrasonic-based autofocus system
TroCAM Basic / Advanced
CAD / CAM software for perfect cutting results; nesting-function, lead-
in/lead-out, tool paths, etc. included
TroCare
Comprehensive package of technical services
Dimensions (W x D x H) & Weight
Machine
3.076 x 3.914 x 1.230 mm (121 x 154 x 49 in)
1.600 kg (3.530 lbs.)
Chiller
720 x 835 x 930 mm (117 x 33 x 37 in) (400 watts model)
130 kg (287 lbs.) (400 watts model)
Operating console
800 x 600 x 1.126 mm (32 x 24 x 45 in)
40 kg (88 lbs.)
Travelling exhaust
2.082 x 714 x 2.852 mm (82 x 29 x 113 in)
165 kg (363 lbs.)
Safety
Laser class
Fully enclosed beam path CDRH laser class 4 laser; can be operated
like laser class 2 in standard operation mode
Laser safety
Fully enclosed beam path as well as active laser deflector shield at
working head
Mechanical safety
Light barriers and safety bumpers for beam path and gantry
Interlock
Encoded duplicate interlock safety system
Ambient conditions
Mandatory ambient temperature +15° to +25° C or 59° to 77° F
Humidity 40% to max. 70%, not condensing
Dust free environment (2nd degree according to IEC 60947-1)
Certificates
CE compliant
