I N D I V I D U A L M A R K I N G S Y S T E M S
3. Laser beam alignment on Speedy
What you need:
laser protection glasses (for CO
2
lasers)
the toolbox enclosed to your engraver
masking tape
CAUTION To make sure that there is no laser emission out of a
controlled area establish a limited access area by using non flamable
beam blocking curtains, temporary walls or other enclosures.
CAUTION The laser beam alignment may only be performed by service
technichians that have been trained by Trotec and are familiar with the
hazards from lasers
CAUTION
Never expose any part of your body to the beam as this could result in
serious injuries.
CAUTION
To do the alignment it is absolutely necessary to wear laser protection
glasses.
What you have to know:
The number of the mirrors is counted from the outlet of the laser tube to the
engraving head from one to three.
The whole alignment is done while your machine is running. To make sure the
system works at a suitable power level switch your machine off and on again.
The laser beam is invisible. To make it visible, you use adhesive tape. It is burned at
the spot, where it is hit by the laser beam and shows so a mark.
The tolerable displacement (distance from burned dot to the centre) is one sixth of
the diameter of the mirror or hole where you check the position.
