Trotec Speedy C25 User Manual

NORMAL.DOT Gespeichert in:G:\Support\Dokumentationen_CDs\8003Speedy\Service Manual\Servicemanual 8003.doc Gespeichert am:2003/03/10
max Version 14
Seite 85 von 87
I N D I V I D U A L M A R K I N G S Y S T E M S
Recommended replacement intervals for wear-and-tear parts
Trotec recommends the below mentioned replacement intervals. The life time will in
many cases be much longer. But as we want to prevent a loss of engraving precision
wear-and-tear parts should be replaced regularely.
All mentioned hour ratings are laser hours.
Amount
Part no.
Part name Replacement interval
laser tube when a problem occurs
(expected after 2000h)
1 79758 Motor belt X-axis 1500h or 1year
1 79830 Motor belt Y-axis 2500h or 2years
1 80620 Main belt X-axis 1500h or 1year
1 80621 Main belt Y-axis 2500h or 2years
1 78330 Main belt Z-axis 4000h
1 79112 X-axis motor 1500h or 1year
1 80959 Y-axis motor when a problem occurs
1 80958 Z-axis motor when a problem occurs
2
2
79756
79757
Ball bearings X-axis 1500h or 1year
4
4
79756
79827
Ball bearings Y-axis 2500h or 2 years
6 79850 Ball bearings Z-axis when a problem occurs
1 80735 Gearing assembly X-axis 1500h or 2years
1 79820 Gearing assembly Y-axis (left) 2500h or 3years
1 80962 Bearing assembly Y-axis 2000h
1 79828 Drive gear Y-axis 2500h
1 79814 THK guide X-axis 2500h
1 79832 THK guide Y-axis 3500h
1 75036 Mirror 1 when a problem occurs
1 79134 Mirror 2 when a problem occurs
1 79135 Mirror 3 when a problem occurs
1 74323 Lens when a problem occurs
