• Open the Trotec manager and connect to the engraver
• Enter the Advanced Options menu (Settings>Advanced options, Tab
Testpulse) and switch Power Testpulse to 100%. Press update.
increasing the test pulse to full power
• Defeat the interlock by plugging the interlock defeat tool into the socket on
the left side of the engraving area.
• Remove the lens
• Put the power meter with the black absorbing area in one of the corners of the
engraving table
• Move the table to a height level so that the distance between engraving head
and target area is approximately four centimetres.
setup for measuring the laser power
• Press the reset button on the power meter and fire the testpulse (press test,
keep it pressed and then press service)
• After some seconds you will hear a beep sound, which indicates that the
measurement has been finished.
• Repeat the procedure in the other corners
interlock
defeat tool
