Troxler 4140 User Manual

Model 4140
3-1
CHAPTER 3
CALIBRATION AND ADJUSTMENTS
This chapter discusses calibrating the Model 4140 Gyratory
Compactor and adjusting the angle of gyration.
CONTENTS
Calibration Schedule ...................................................................... 3-2
Calibrating the Unit ....................................................................... 3-3
Pressure ................................................................................... 3-3
Specimen Height ..................................................................... 3-6
Angle of Gyration.................................................................... 3-8
Rotation Speed ...................................................................... 3-14
Print Calibration .................................................................... 3-15
Adjusting the Angle of Gyration.................................................. 3-16
Converting the Unit for Small Angles ......................................... 3-18
Changing the Mold Size .............................................................. 3-21
3. CALIBRATION

Troxler 4140 Specifications

General

Brand	Troxler
Model	4140
Category	Laboratory Equipment
Language	English
