4-10
SLIDE MOLD INTO
TOP OF EXTRUDER
TOP VIEW
USE EXTRUDER HANDLE
TO PUMP THE EXTRUDER
TURN BLACK KNOB
CLOCKWISE TO
CLOSE VALVE
ADJUSTABLE FEET
Figure 4-2. Mold in the Extruder
