Troxler 4140 User Manual

Model 4140
A-13
✓ Reinstall the clean washer.
✓ Generously coat the top of the washer with Magnalube-G.
✓ Reinstall the clean bearing.
✓ Generously coat the top of the bearing with Magnalube-G.
✓ Apply Magnalube-G to the inside diameter of the cavity
(see Figure A-1).
✓ Reinstall the clean o-ring in the groove around the clean
turntable. Ensure the o-ring is fully seated in the groove.
✓ Carefully insert the turntable into the cavity.
✓ Ensure that the plate is fully seated and the o-ring is still
properly installed around the turntable.
✓ Reinstall the clean retainer. Tighten the six 4-40 x 1/4"
flathead screws in a crisscross pattern.
Every 500 Hours of Operation or Once a Year
✓ Add grease to the ram as follows:
✓ Remove the cover from the lower grease fitting.
✓ Add three to four pumps of Mobilith→ AW-1 to the lower
grease fitting.
✓ Replace the lower grease fitting cover.
✓ Remove the upper grease fitting cover.
✓ Add one to two pumps of Mobilith AW-1 to the upper
grease fitting.
✓ Replace the upper grease fitting.
A. TROUBLESHOOTING
