13
NOTE:
※Moving range of the transfer unit: 5mm
When the transfer unit is at its innermost
position (nearest position from the cutting
wheel), after cutting, the distance from the
cutting position to the clamp surface is
approx. 0.6 ~ 0.7mm.
After grinding, this distance is approx. 0.5mm
● The fixing screw must be tightened firmly before operation. Otherwise, it may cause
damage to the device.
● When grinding the surface again, only move the clamp to the front 0.2mm or less each
time. Otherwise, it may cause damage to the device.
