8.2 ASSEMBLING THE GRINDING WHEEL
1. Remove the clamp from the transfer unit.
Close the safety cover.
On LCD operation panel, select Setting
button.
→ CS07 setting screen appears
2. At Slide Clamper, select Right button
→ The transfer unit will move to the right.
→ Turn off the power of CS07.
3. Open the metal protective cover by sliding it to
the left while holding the metal knob (red circle)
4. On the cutting side, remove the standard cutting wheel by rotating the flange clockwise.
※Do not rotate the flange counterclockwise.
To Next Page
