24
7 BIG WIRE CROSS SECTION
With CS07 big-wire cutting option, it is possible to cut up to 60sq terminals (Length: 14mm
or less, Width: 20mm or less).
Cross sections of big wires are very clean and clear, even without grinding.
CS07 automatically recognizes and switches to big-wire cutting mode based on the clamp
placed on the transfer unit.
Appicable wire range: AWG10 ~ AWG1/0
※Distance from the cutting and grinding wheel to CS07 cover: 30mm.
If the terminal mating section is longer than that, please cut it off before operation.
7.1 BIG WIRE CUTTING OPTIONAL COMPONENTS
Big wire clamp
Vacuum Unit
0.5X auxiliary lens
