TSC ME240 User Manual

47
Bline Mode
Scan Mark
Intensity x
Ref. Level xxx
3. Open the print head mechanism, put the black
mark under the media sensor. Press the
button to set the value into the
printer.
Bline Mode
Scan Paper
Intensity x
Ref. Level xxx
4. Then, put the label without black mark under
the media sensor. Press the
button to set the value into the printer.
Note:
Normally, the value of “Ref. Level” for mark should be larger than paper for over
128. If the media sensor fails to do so, you have to manually change the
Intensity by pressing and to reach the above value.
Bline Mode
Complete
Intensity x
Ref. Level xxx
5. The bline sensor calibration is complete.
Press the button the LCD screen
will return to the previous menu.
B-3 Pre-Printed
This function will need to set the paper length and gap size before auto-calibrate the
sensor sensitivity. It can get the sensor sensitivity more accurately for pre-printed
media.
Bline Mode 3/4
Manual
>
Pre-Printed
Exit
Media sensor
Black mark
Media sensor
Label without black mark

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
