TSC ME240 User Manual

48
When enter [Pre-Printed] option, you will see following message. Please complete
there steps：
Paper Len.
00812 dot
1. Press the button to move
the cursor from left digit to right digit,
and press the button to set
the value from “0” to “9” and the “dot/
mm/ inch”. Press the
button to set the paper length into the
printer.
Bline Size
0024 dot
2. Press the button to move
the cursor from left digit to right digit,
and press the button to set
the value from “0” to “9” and the “dot/
mm/ inch”. Press the
button to set the bline size into the
printer.
Bline Mode
Pre-Printed
3. Then, printer will feed labels to
calibrate the sensor sensitivity
automatically. When calibration is
completed, the LCD screen will return
to the previous menu.

TSC ME240 Specifications

General

Resolution	203 dpi / 300 dpi
Operating Temperature	5°C to 40°C (41°F to 104°F)
Print Method	Thermal Transfer & Direct Thermal
Interface	USB
Power Supply	AC 100-240V, 50/60Hz
Humidity	20% to 85% RH (non-condensing)
