25
2.7 Adjustment Knob
2.7.1 Print head Pressure Adjustment Knob
The print head pressure adjustment knob has 5 levels of adjustment. Because the
printer’s paper alignment is to the left side of mechanism, different media widths
require different pressure to print correctly. Therefore it may require to adjust the
pressure knob to get your best print quality. For example, if the label width is 4”, adjust
both print head pressure adjustment knobs to the same level. If the label is less than 2”
wide, increase the left side print head pressure by rotating the adjustment knob
clockwise and decrease the right side pressure by rotating the adjustment knob
counter-clockwise to level 1.
2.7.2 Print Head Burn Line Adjustment Knob
The print head burn line adjustment knobs are used to fine tune the print quality for
Print head pressure
adjustment knobs
Print head burn line
adjustment knobs
