TSC TTP-2410M - 3.5 Service

63
3.5 Service
Service
Initialization Mileage Info. Exit
This feature is used to restore printer settings to defaults and display printer mileage
information.
3.5.1 Initialization
Service 1/3 Initialization Initializing ...
> Initialization
Mileage Info. SELECT YES
Exit MENU NO
The printer settings are restored to defaults as below once printer is initialized.
Note :
When printer initialization is done, please calibrate the gap or black mark sensor
before printing.
Parameter Default setting
Speed
TTP-2410M： 6 IPS (152 mm/sec)
TTP-346M/246M Plus/344M Pius：4 IPS (101.6 mm/sec)
TTP-644M： 3 IPS (76.2 mm/sec)
Density
8
Label width
4.00"(101.6mm)
Label height
4.00"(101.6mm)
Sensor type
Gap sensor
Gap setting
0.12"(3.0mm)
Print direction
0
Reference point
0,0(upper left corner)
Offset
0
Print mode
Batch mode
Serial port settings
9600 bps, none parity, 8 data bits, 1 stop bit
Code page
850
Country code
001
Clear flash memory
No
Shift X
0
Shift Y
0
