27
2.8 Using the Keyboard with PS/2 Interface (Optional for TTP-246M
Plus/TTP-344M Plus models)
1. Turn off the power of printer.
2. Plug the keyboard with PS/2 interface cable into PS/2 connector on the rear of the
printer.
3. Turn on the printer.
4. After press the F1 key of the keyboard, the LCD of printer will display as following.
5. Use up
or down key of the keyboard to move “>” cursor and to select either
DRAM, FLASH or CARD that you previously saved file in and press Enter key of
the keyboard to list files.
6. Select the file and press Enter key to execute the .BAS file.
7. Then, you can type the words or the number of the copy from keyboard by
your .BAS file program.
Press F1 key of the keyboard to start this function.
Press up or down key of the keyboard to move cursor of printer LCD display to select
the option.
Press Esc key of the keyboard to return the previous menu.
Press Enter key of the keyboard to enter/execute cursor located option.
Press Ctrl + C keys of the keyboard to restart the printer and back to “Ready” state.
Note: PS/2 interface is standard interface for TTP-2410M/TTP-346M models, but
optional for TTP-246M Plus/TTP-344M Plus models.
File List 2/4
DRAM
> FLASH
CARD
FLASH File List
TEST1.BAS
> TEST2.BAS
TEST3.BAS
