49
Bline Mode
Scan Mark
Intensity x
Ref. Level xxx
3. Open the print head mechanism, put
the black mark under the media
sensor. Press the
button
to set the value into the printer.
Bline Mode
Scan Paper
Intensity x
Ref. Level xxx
4. Then, put the label without black mark
under the media sensor. Press the
button to set the value into
the printer.
Note:
Normally, the value of “Ref. Level” for mark should be larger than paper
for over 128. If the media sensor fails to do so, you have to manually
change the Intensity by pressing
and to reach the
above value.
Bline Mode
Complete
Intensity x
Ref. Level xxx
5. The bline sensor calibration is
complete. Press the
button the LCD screen will return to
the previous menu.
B-3 Pre-Printed
This function can set the paper length and gap size before auto-calibrate the
sensor sensitivity. It can to get the sensor sensitivity accurately.
When enter [Pre-Printed] option, you will see following message. Please
complete there steps：
Bline Mode 3/4
Manual
> Pre-Printed
Exit
Media sensor
Black mark
Media sensor
Label without
black mark
