2
TTP-243 Bar Code Printer
Service Manua
l
1.3 Overview
1.3.1 Front View
Fig. 1.1 Front View of TTP-243
Note: The one difference between TTP model and TDP model is the ribbon
mechanism.
Front Panel
Cover Release Button
Top Cover
Operation Panel
