TTP-243 Bar Code Printer
Service Manua
l
2. SUPPLY SPECIFICATIONS
2.1 Types of Paper
Two types of media are available for TTP-243: label and ticket.
In TTP-243, there are two types of sensors for paper: gap sensor and black mark
sensor.
Label and ticket can be further classified into direct thermal type or thermal transfer
type.
2.2 Specifications
Items Label
Max.114mm
Paper Width
Min. 25mm
Length (Pitch)
12∼2286mm
Paper
Thickness
0.20 mm
Paper Weight Max 240 g/m
2
Inner roll diameter. Max 4.3” (110mm)
Max. Roll
Diameter
(1” core)
External roll diameter. Max 8.4”
(214mm)
Roll Up Method Print surface wound outside as standard
Paper Core ID.
φ25.7±0.3mm
Note: (1). The width and thickness quoted above are said of the label plus its backing
paper.
(2). Likewise, the approval of label entails that of its backing paper.
(3). In the peel off mode, the minimum pitch is 35mm.
(4). In the cutter mode, it is required the paper be wound outside. Otherwise,
paper jam tends to result.
(5). In the cutter mode, the paper thickness is 0.2 mm at maximum, and the paper
weight is 100 g/m
2
at maximum.
(6). Paper shape is as shown on next page.
(7) Tag is 0.2mm in thickness, and is less than 100g/m
2
in weight.
