4
TTP-243 Bar Code Printer
Service Manua
l
1.4 Basic Specifications
Thermal transfer and direct thermal printing
High dot density printing (203 dots/inch)
Selectable print speeds at 1.5”, 2.0” or 3.0” per second
Supports parallel and serial interface
Maximum media width up to 4.4” (114 mm)
Adjustable label edge guide
International character sets
Print area is 4.09”W x 90”L (without any file downloaded in the printer memory)
User selectable bar code ratios and heights
Prints on labels or tickets
Equipped with black mark sensor
Equipped with Real Time Clock
Comes with self-peeling function
Buzzer provided to warn of possible errors
Label stock and thermal transfer ribbon are easy to install
Internal label print counter
Self test and hex dump mode
Downloadable fonts from label design software
Electronics/Communication Specifications
Electrical
CPU: MITSUBISHI M37720S1BFP
TPH: ROHM 4” KF-2004-GC17B
Stepping Motor: Mitsumi
DC Motor: DC24V
Memory:
─DRAM: MOSEL 2 Mb.
─Flash: ATMEL 1 Mb
Adapter 100~240VAC±10%, 50~60Hz
Regulations: CE, FCC, UL, CUL, TÜV-GS, CNS
Communications Interface:
Serial port: RS-232C (DB-9) at 2400, 4800, 9600 or 19200 baud rate
─Word Length: 7 or 8 data bits, 1 or 2 stop bits, selectable parity
─Handshaking: XON/XOFF and DSR/DTR
Parallel port: Standard parallel interface
Input Buffer: 60KB
