TTP-244 Plus Bar Code
Printer Service Manual
2. SUPPLY SPECIFICATIONS
2.1 Types of Paper
Two types of media are available for TTP-244 Plus: label and ticket.
In TTP-244 Plus, there are two types of sensors for paper: gap sensor and black mark
sensor.
Label and ticket can be further classified into direct thermal type or thermal transfer type.
2.2 Specifications
Items
Label
Paper Width
Max.114mm
Min. 25.4mm
Length (Pitch)
10～1016mm
Paper
Thickness
0.25 mm
Paper Weight
Max 240 g/m
2
Max. Roll
Diameter
(1” core)
Inner roll diameter. Max 4.3” (110mm)
External roll diameter. Max 8.4”
(214mm)
Roll Up Method
Print surface wound outside as
standard
Paper Core ID.
25.7±0.3mm
Note:
(1). The width and thickness quoted above are said of the label plus its backing paper.
(2). Likewise, the approval of label entails that of its backing paper.
(3). Paper shape is as shown on next page:
