TSC TTP-244 Plus Service Manual

33
TTP-244 Plus Bar Code
Printer Service Manual
5. TROUBLE SHOOTING
5.1 Trouble Shooting
Problems
Solutions
1. Ribbon does not advance.
Check the printing mode setting and reset the
printer.
2. Poor print quality.
Clean the print head.
Adjust the print density setting.
3. Only prints diagonal pattern in the self-test.
Ribbon and paper are incompatible. Use a
different type of ribbon.
4. Power indicator light does not illuminate.
Check the connection of serial port cable.
5. On-line indicator light does not to illuminate.
Check the DIP switch setting and reset the
printer.
Check that power cord is properly connected.
6. Error indicator remains illuminated.
Out of paper or out of ribbon.
Check the DIP switch setting
Check the paper core, make sure it is installed
on the ribbon rewind spindle.
Press the FEED key. The error message will
be printed out on the print media or sent out
through RS-232 port.
If there is no problem with direct thermal
printing, but error occurs in thermal transfer
printing. Please check the encoder of the DC
motor.

TSC TTP-244 Plus Specifications

General

Resolution	203 dpi
Print Speed	4 ips
Print Method	Thermal Transfer / Direct Thermal
Weight	2.5 kg
Max. Print Width	4.25 inches
Max. Print Length	90 inches
Processor	32-bit RISC CPU
Interface	RS-232
Label Width	1 inch to 4.4 inches
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Humidity	25% to 85% non-condensing
Label Thickness	0.06 ~ 0.19 mm (2.36 ~ 7.48 mil)
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D)
