3
TTP-244 Plus Bar Code
Printer Service Manual
1.3.2 Rear View
Power Supply
Connector
RS-232 Interface
Connector
USB Interface
Connector
Label Insert
Opening (for use
with external
labels)
Power On/Off
Switch
Centronics Interface
Connector (Option)
