TTP-244 Plus Bar Code
Printer Service Manual
4.6 Stepping Motor Replacement
1. Follow the instructions in Section 4.2 to take out the mechanism.
2. Remove the two screws on stepping motor fixture.
3. Replace the stepping motor and reassemble the removed parts in the reverse order of removal.
Screws
